Diamond Shape Firm Stable 2mm Wire Rope Netting Rust Resistance

Name: Diamond Shape Firm Stable 2mm Wire Rope Netting Rust Resistance
Brand: X MESH
Price: 3.5 USD

Diamond Shape Firm Stable 2mm Wire Rope Netting Rust Resistance Manufactures

Brand Name : X MESH

Model Number : X MESH-Cable Webnet-004

Certification : ISO9001:2015

Place of Origin : Hebei P.R. China.

MOQ : 100m2

Price : USD3.5-5.85/m2

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 5000m2/week

Delivery Time : 5-7days

Packaging Details : Wrapped with plastic film and pallet packing

Product Name : Wire Rope Net

Material : Stainless Steel 316

Wire Rope : 2mm

Rope Constructions : 7 X 7

Mesh Shape : Diamond

Application : for safety nets

Panel Size : 2m(H) x 3m(L)

Mesh Angle : 60 Degree

Feature : Firm & Stable

Packing : Carton or Wooden Case Packing

Contact Now

Wire Rope Net X Tend Mesh Cable Webnet with 2mm Wire Diameter for safety nets

Wire Rope Net Introduction:

The stainless steel ferrule rope mesh is manufactured from robust, high-grade DIN 1.4401/AISI 316 stainless steel cables. The cables are swaged with stainless steel, copper or aluminium clamps in a special process to form a mesh structure that is both stressable and flexible and suited for either two- or three-dimensional applications. The stainless steel net is suited for interior and exterior applications.Installed on railings or in stairways, it provides stability and clear guidance. On façades, it can serve as a climbing support for plants or it can set delicate accents as a dividing element in large spaces.

Product Name	Wire Rope Net
Material	Stainless Steel 316
Wire Rope	2mm
Rope Constructions	7 X 7
Mesh Shape	Diamond
Application	for safety nets
Panel Size	2m(H) x 3m(L)
Mesh Angle	60 Degree
Feature	Firm & Stable
Packing	Carton or Wooden Case Packing

Wire Rope Net Standard Specification:

Material:	Stainless Steel 304 , 316 , 316L	Wire Rope:	1.2 Mm To 4.0 Mm
Rope Constructions:	7 X 7 , 7 X 19 , 1 X 19	Finished:	Ultrasonic Bath / Black Oxide
Mesh Orientation:	Horizontal , Vertical	Product Name:	Inox X-tend Cable Mesh Webnet
Mesh Shape:	Rhombus , Diamond	Application:	Staircase Security , Balustrade Infill , Railing Safety
Panel Size:	Customized In Width And Length	Mesh Angle:	60 Degree
Mesh Style:	X-tend In Ferruled Type

Common Specifications:

Hole Size (Opening)	1.2MM(3/64) (7 x 7 )	1.6MM(1/16) (7 x 7 )	2.0MM(5/64) (7 x 7 )	2.4MM(3/32) (7 x 7 )	3.2MM(1/8) (7 x 19 )
20 x 35mm	QJ-1235
25 x 42mm	QJ -1225	QJ -1625
30 x 52mm	QJ -1230	QJ -1630	QJ -2030
35 x 60mm	QJ -1235	QJ -1635	QJ -2035
38 x 66mm	QJ -1238	QJ -1638	QJ -2038	QJ -2438
40 x 69mm	QJ -1240	QJ -1640	QJ -2040	QJ -2440	QJ -3040
50 x 86mm	QJ -1250	QJ -1650	QJ -2050	QJ -2450	QJ -3050
60 x 104mm	QJ -1260	QJ -1660	QJ -2060	QJ -2460	QJ -3060
70 x 120mm	QJ -1270	QJ -1670	QJ -2070	QJ -2470	QJ -3070
76 x 131mm	QJ -1276	QJ -1676	QJ -2076	QJ -2476	QJ -3076
80 x 138mm	QJ -1280	QJ -1680	QJ -2080	QJ -2480	QJ -3080
90 x 154mm	QJ -1290	QJ -1690	QJ -2090	QJ -2490	QJ -3090
100 x 173mm	QJ -12100	QJ -16100	QJ -20100	QJ -24100	QJ -30100
120 x 206mm	QJ -12120	QJ -16120	QJ -20120	QJ -24120	QJ -30120

Material of Stainless Steel Zoo Wire Mesh : Stainless steel 304,304L,316,306L etc.

SS304	(%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316	(%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L	(%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0

Recommended Balustrade Infill Cable Wire Mesh

Material	Cable Diameter	Hole Size	Normal Break
SS304/316/316L	1/16" (1.6MM)	2.5" x 2.5"	480 LBS
SS304/316/316L	1/16" (1.6MM)	2" x 2"	480 LBS
SS304/316/316L	5/64" (2.0MM)	2.5" x 2.5"	676 LBS
SS304/316/316L	5/64" (2.0MM)	2" x 2"	676 LBS
SS304/316/316L	5/64" (2.0MM)	3" x 3"	676 LBS

Wire Rope Net Feature:

Handle Made
Environmental Protection
Extensive Use
Premium Quality
Direct from Factory
Product Life Cycle
Lifetime Support

Wire Rope Net Application:

Suspension Bridge Railing Mesh
Stainless steel rope mesh is also mainly used in the suspension bridge railing.
Helideck Mesh
Stainless steel rope mesh can ensure the safety of helicopters and passengers when it is used as the helideck mesh. It is
installed around the helicopter landing deck.
Balustrade Mesh
Stainless steel rope mesh is also used for the balustrade of stair or balcony. It can make the stair grand, beautiful and safer.
Decoration Mesh
The diamond-shaped holes make the stainless steel rope mesh have aesthetic appearance, so rope mesh can be used for decoration of
building, such as ceiling and curtain wall.
Green Wall
Stainless steel rope mesh is resistant to corrosion and rust even though it is exposed to sun directly. And it can make the green
wall with green plants. Green wall can regulate the temperature of the building and it can protect the building wall.
Aviary Netting
The mesh size and opening size of stainless steel rope mesh can be modified. So it can provide enough space and create a natural
environment for birds to make them live comfortably.
Zoo Mesh
Stainless steel rope zoo mesh has diamond-shaped openings and high strength, which can protect visitors from being damaged.
Therefore, visitors can enjoy the animals at a close distance free of danger. What's more, it can protect animals from being hurt.
Slope Protection Rope Mesh
Slope protection rope mesh has enough intercept strength to prevent the rocks from slope falling onto road, railway, expressway or
other structures. Instead, rocks will fall to the foot of slope behind the rope mesh.
